Concrete Unrolled
Faster, stronger, less expensive, and no cement trucks

A New Concrete

Cortex is an innovative concrete that is applied in rolls and does not require a cement truck to install. Just unroll, add water, and Cortex becomes two-times stronger than standard concrete. Cortex technology is classified as a GCCM (Geosynthetic Cementitious Composite Mat).

ASTM Geosynthetic Cementitious Composite Mat
Full reports here.

Key Benefits

Cortex technology outperforms standard concrete in several key ways:

  • ⚖️ 90% less material than standard concrete.
  • ♻️ 90% carbon savings from traditional concrete.
  • ⏱ 20x faster to install than standard concrete (no mixing, rebar, formwork, or finishing).
  • 🛠 No high-skill workers required.
  • 💪 Over 2x the compressive strength of standard concrete.
ASTM Geosynthetic Cementitious Composite Mat
Full reports here.

Composite Layers

💧 Water Soluble Material

A water soluble fabric holds the cement in place during installation, allowing water to pass through, and eventually disintegrating.

🌀 Proprietary Cement Mix

Gels when wet to lock the mix in place, sets quickly, and produces much stronger concrete than alternatives.

🌐 3D Reinforcement Matting

A framework of 3D matting holds the mix and then reinforces it after installation and watering.

🛡 Water-Proof Membrane

Provides 100% water-proofing, and inhibits chemicals from soil (eg. sulfate attack).

Performance Stats

  • ⬇️ Compression Strength: 7,000 psi (AMST C-109)
  • 💪 Flexural Strength: 1500 psi (AMST C-947)
  • ⛏ Punctural Resistence: 1,500 psi (AMST D-4833)
  • 📦 Packaging: 8’ x 100’ x 0.5

One great product, many applications.

Cortex makes all kinds of jobs easier and more cost effective.

💧 Water Management
  • Ditches & Canals
  • Shoreline Management
🌾 Agriculture
  • Canals & Ditches
  • Pits & Ponds
🗑Landfill & Waste
  • Waste Lagoons
  •
Capping
🛢Oil & Gas
  • Pits & Ponds

  • Ditches

  • Secondary Containment
🛣Transportation
  • Roads
  • Ditch Lining
  • Erosion Control

⛏Mining
  • Ditches & Canals
  •
Leach Pads

  • Pits & Ponds

Agriculture &
Canal Lining

Cortex can be used in canal, ditch, and pond lining applications for agriculture. Cortex can be used for ditches where medium to high water velocities and shear forces are expected. Cortex can be used to prevent erosion along the walls of ponds and reinforce them to create a permeant watershed.

Erosion Control

Cortex can be used in water management applications for ditch lining. Cortex can be used for ditches where medium to high water velocities and shear forces are expected. Cortex can be used to prevent erosion along channels and runoff drain-ways to protect the structures from the erosive effects of flowing water.

Containment

Cortex can be used for water reservoirs, remediation ponds for agriculture and oil & gas applications. Cortex can be used for a wide range of containment applications including primary and secondary containment of waste or process liquids. Cortex can prevent the contamination of ground water, rivers and streams resulting from improper containment of toxic and hazardous waste, mining heaps, composting sites and landfills.

Road Construction

Cortex is currently undergoing testing as a material for roads. The installation process greatly reduces construction time, costs, and maintenance. Cortex resists the deterioration and standard weathering processes of asphalt and pavement roads.

Installation Process

Cutting construction times for standardized applications

Cortex’s simplified installation process minimizes construction time and requires no high skill construction experience. Small teams can complete standard canal and ditch projects in just days.

Step 1

Prep project site per application

Step 2

Unroll across site

Step 3

Fasten lining and seams of rolls

Step 4

Hydrate and let dry

Ready for Use
